After extraction without drilling, a 4x11 mm dummy implant is placed as a tap drill with satisfactory stability (Fig.5).  To get subcrestal placement, a shorter (4x9 mm) implant is inserted with insertion torque of >35 Ncm (Fig.6).  In retrospect, a larger implant (4.5 mm) would be better in term of primary stability.  After allograft placement into the buccal and lingual gaps, a 4.5x4(4) mm abutment is placed for an immediate provisional.  The sinus floor is penetrated by the implants without bone graft for sinus lift.  There is a peri-implant gap 7 months postop (Fig.7<) .  When the loose abutment is being retightened, the patient feels pain, although the gingiva appears healthy (Fig.8).  A larger implant should have been used; the abutment should have been removed.

The implant dislodges while the abutment is untightened 8 months postop.  The osteotomy is found intact.  A 4.5x11 mm dummy implant is placed 2 mm subgingival with 20 Ncm (Fig.9).  When a 4.5x11 mm definitive implant is placed 3 mm subgingival (Fig.10,11), torque reaches 50 Ncm.  A 5.5x3 mm healing abutment is placed.
