After adjustment of trajectory, a 4x11 mm definitive implant is placed at #14 with ~ 35 Ncm, while a 6x9 mm implant is placed at #15 with ~35 Ncm (Fig.2 (*: Vanilla Graft with Osteogen)).  The patient returns 3 months postop (Fig.3).  After changing abutments to 5.5x5.7(3) mm, impression is taken.  While there is distal bone resorption (arrow (due to the large abutment/pressure?)), the mesial bone graft retains (*).

Depth Control Last Next

Xin Wei, DDS, PhD, MS 1st edition 02/26/2018, last revision 01/14/2020
