Guided Implants for FPD

With 34 mg of Lidocaine and 17 mcg of Epinephrine, implants are placed at #12 and 14 without discomfort (45 and 15 Ncm, Fig.1).  Since the bone density at #12 is higher than that at #14, implant is placed at #12 first.  With fixture anchor pin placed at #12, osteotomy and implant placement at #14 is much easier  than those at #12 because of one free hand.  Probably due to limited mouth opening and TMJ dislocation, these two implants are not placed in parallel.

Return to Upper Molar Immediate Implant, Armaments

Xin Wei, DDS, PhD, MS 1st edition 09/20/2018, last revision 01/21/2019
