Dense Bone Appears to
be Peripheral and Deep
With one carpule of 2% Xylocaine with 1:100,000 Epinephrine, there is no intraop pain associated with placement of 2 implants with guide (Fig.1). Postop pain is minimal. Difficulty is high torque in insertion. At the site of #15, there is no bone shaving associated with 4 mm or less drills. The deeper portion of the bone seems to have denser bone. In spite of using 5 mm tap, which is not recommended, the insertion torque is so high that the implant has to be backed up several times before placement with ~ 50 Ncm. Bone profile is used at #14 before placement of a 5.5x7 mm healing abutment. The healing abutment at #15 dislodges 3 weeks postop and changes to a 5.5x5 mm one. No bone loss is observed 4 months postop (Fig.2). After failure to deliver crowns using impression coping, abutments are placed. The one at #15 is incompletely seated (Fig.3 <) probably due to the contact with the distal crest (*). Change to a smaller one results in complete seating (Fig.4). Cementation of the crowns with access holes is related to no residual cement (Fig.5).
