For safety, a 4x9 mm IBS implant is placed with insertion torque 40 Ncm; a 5x5.7(4) mm abutment is immediately placed for an immediate provisional to cover the large socket and keep Vera graft in place (Fig.4 *).  Yellow dashed line: apical osteotomy; red dashed line: Mental Loop.  Impression is taken nearly 3 months postop (Fig.6). The bone density around the implant increases 7 months post cementation (Fig.8 *).  The higher density bone seems to extend coronally 1 year 7 months post cementation (Fig.9).  The dense bone apparently extends toward the abutment as well 3 years 5 months post cementation (Fig.10 curved arrows).

Return to Mental Loop Last Next  智齿拔除

Xin Wei, DDS, PhD, MS 1st edition 07/16/2021, last revision 07/18/2021
