A drawback of implant planning at #25 is not to use a preop PA (Fig.1 (^ fracture line)).  The initial trajectory seems to be alright (Fig.2 (red line: socket; D: 1.2 mm drill)), but a 2.5x14(2) mm implant placed is close to the tooth #26 (Fig.3 (allograft having been placed)).  The latter may be related to more bone loss in the distal crest 3.5 months postop (Fig.8) and more severe distal papillary recession (Fig.9 *).  The meisal bone seems to be wider.

Trajectory Last Next Xin Wei, DDS, PhD, MS 1st edition 09/17/2019, last revision 09/17/2019
