By breaking the proximal contacts, the crown, abutment and implant at #14 are shaken loose using forceps.  Finally the crown breaks off.  Make a slot on the top of the abutment and use a screw bit to turn the abutment/implant counterclockwise.  There is abundant granulation tissue with arterial hemorrhage associated with removal.  The defect involves the distal surface of the implant at #13 and the mesial surface of the tooth #15.  Therefore bone graft is deposited in these surfaces (Fig.4 arrowheads).  The bone height 5.5 months postop should be enough for implantation (Fig.6).

Lingual Defect Last Next

Xin Wei, DDS, PhD, MS 1st edition 02/21/2019, last revision 08/01/2019
