The implant is placed deeper ~ 1 mm, followed by a 5.5x3 mm healing abutment (Fig.6 (*: sinus lift)).  There is faint bone graft around the apex of the implant 4 months postop (Fig.10).  The implant sustains 25-30 Ncm torque when a 5.2x4(3) mm cemented abutment is placed.

Setback Last Next Xin Wei, DDS, PhD, MS 1st edition 11/19/2019, last revision 12/04/2019
