Socket Shield Prevents Gingival Recession

A 89-year-old man has poor dentition (Fig.1).  After caries control (Fig.2), implants are placed at #7 and 8 (Fig.3).  Because of the buccal plate fracture associated with extracted the ankylosed tooth #8, postop gingival recession occurs (Fig.3 arrow).  To prevent the complication, socket shield will be performed if extraction of the tooth #10 turns out to be difficult.  A 2.5 or 3x16 mm 1-piece or 3.5x13 mm/3.8x15 mm 2-piece implant will be attempted to be placed.  Take preop photos to show #7 and 8 crowns and #10 residual root .  Incision may be made to expose the labial crest to make sure that the the remaining labial portion of the root is caries free after extraction with sectioning.

Return to Upper Incisor Immediate Implant, IBS, Armaments, Metronidazole

Xin Wei, DDS, PhD, MS 1st edition 10/08/2017, last revision 01/19/2018
