Root Fracture of Lateral Incisor with Possible Buccal Plate Defect

A 52-year-old man had a non-restorable lateral incisor 3 years ago (Fig.1).  It fractures lately (Fig.2) with a buccal abscess (Fig.3 *) ) and fistula (>, possible severe buccal plate defect, prepare PRF).  Severe deep bite (Fig.4) and malocclusion (Fig.5) will present a challenge to implant provisional restoration.

After extraction (no Antibiotic socket treatment), start osteotomy in the palatal wall for a few mm in the native bone, insert a parallel pin and check bite.  Adjust the trajectory and position of the osteotomy as early as possible.  If the bone is dense, extend osteotomy depth to 18 mm for a 3.8x15 or 16 implant.  Otherwise 20 mm for 3.8x18 mm one.  The final drill will be 2-3 mm shorter if the bone density is low.

If the deep bite is a problem, place a healing abutment or the immediate provisional without the palatal apical wall.  Or ask the patient in advance whether the right lateral can be placed as labial as the tooth #10 or not (Fig.3-5).

Return to Upper Incisor Immediate Implant, IBS Xin Wei, DDS, PhD, MS 1st edition 01/24/2017, last revision 12/30/2018
