From Root Fracture to Crown Dislodgement to Residual Roots

A 59-year-old man had large caries at the tooth #15 in 2009 (Fig.1).  There is sign of root fracture in 2014 post RCT (Fig.2, unilateral mastication: #31 missing).  Now the affected tooth turns into residual roots with #16 mesial shift (reduced mesiodistal dimension at the edentulous area).  A long, relatively narrow implant is to be prepared (Fig.1,2).  Take PA preop to confirm that radiolucency is reduced after tooth fracture and residual root coronal displacement.

Return to Upper Molar Immediate Implant, Prevent Molar Periimplantitis (Protocols, Table), IBS, No Antibiotic

Xin Wei, DDS, PhD, MS 1st edition 10/18/2017, last revision 10/25/2017
