Screw Implant with Low Stability

When the mobile tooth #18 with apical granulation tissue is extracted, the socket is large and long (close to the Inferior Alveolar Canal (Fig.2,3 red dashed line).  Without drilling, a 7 mm bone level tap does not obtain stability.  A 8x17 mm tapered tap reaches the bottom of the socket with minimal stability, but coronally it is close to the tooth #32 (Fig.1).  When a 7x14 mm cylindrical tap is placed, it is shy of the bottom of the socket (Fig.2 *), but the trajectory improves.  A 7x14 mm tissue-level implant is placed with ~45 Ncm (still not secure) with Vanilla graft placed mainly distolingually (Fig.3).  With the large implant, the socket is closed 8 days postop (Fig.4).  The soft and hard tissues appear to heal 3 months postop (Fig.5,6).  A healing abutment (Fig.7 H) is placed to push the mesial papilla mesially (*).  Two weeks later impression is taken with ease because of the healing abutment.  There is no bone loss 4.5 months postop (immediately post cementation, Fig.8).

Return to Lower Molar Immediate Implant, Prevent Molar Periimplantitis (Protocols, Table), Armaments, Successful, Failed Cases Upper

Xin Wei, DDS, PhD, MS 1st edition 04/30/2018, last revision 09/12/2018
