Implant Failure with Sinus Lift

Not long postop, the patient called saying that #2 provisional had dislodged.  Due to his busy schedule and coronavirus outbreak, he returns nearly 4 months postop.  The abutment is distalized and loose with the underlying implant (5x9 mm).  The latter is removed before local anesthesia (Fig.1 distal defect). After initial debridement, a 2.2x13 mm drill is used with a guide of 12 mm offset, followed by insertion of a 4.5x11 mm dummy implant with barely stability (Fig.2).  A 5.5x9 mm is placed free hand initially, followed by guide with stability.  But the implant has uncovered threads distolingual.  Thorough debridement reveals that the sinus membrane has a small perforation.  After placement of a piece of Osteogen plug, cortical chip and Vanilla hydrated with .25 cc of GEM21S is packed into the site with a condenser (Fig.3,4).  The graft is fixed in place with Perio glue, followed by a piece of GEM Cap with the glue.  Three to 4 months later, take CT for healing confirmation.  Try to place a shorter implant (e.g., 5x7 mm) without getting into the sinus to reduce infection.  In fact the Cap does not stay in place with loss of bone graft (8 days postop).

Return to No Deviation GEM21S
Xin Wei, DDS, PhD, MS 1st edition 06/01/2020, last revision 06/09/2020
