10-Year-Comparison

When a 38-year-old man presented to the office 10 years ago, there were 2 missing teeth #2 and 14 with 5.8 mm and 1 mm bone height, respectively (Fig.1).  Later the tooth #15 was extracted.  A 6x11 mm implant was placed with internal sinus lift at #2 first.  Two of 5x11 mm tissue-level implant were placed with lateral window sinus lift at #14,15.  The implant at #14 is loose 3 months post cementation and dislodges later.  Four months post bone graft, a 5x7 mm IBS implant was placed with CMC technique.  With progressive loading at #14, the crown functions 1 year post cementation with the thick bone (Fig.2 *).

Return to Upper Molar Immediate Implant

Xin Wei, DDS, PhD, MS 1st edition 06/03/2018, last revision 09/04/2018
